Xerox PHASER 6010 Service Manual

4-16 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Troubleshooting
Print Settings ■ Ready
■ Processing
Prints the configured settings.
■ Serial No.
■ Tone Correction On/Off
■ Counter Type
■ Full Color Print Count
■ Color 1 Print Count
■ Color 2 Print Count
■ B/W Print Count
■ Tota l Print Co u nt
■ Full Color Backup Count
■ Color 1 Backup Count
■ Color 2 Backup Count
■ B/W Backup Count
■ Total Backup Count
■ Full Color Error Count
■ Color 1 Error Count
■ Color 2 Error Count
■ B/W Error Count
Installation Provides printer installation information.
Serial No.
■ YXLxxxxxx
■ YXMxxxxxx
■ YXNxxxxxx
■ YXRxxxxxx
Displays the 6 digit Serial Number.
This value is read only.
Tone Cor rect ion
■ ON
■ OFF
Specifies whether or not tone
correction is performed.
Pixel Counter
■ Y: nn.n
■ C: nn.n
■ M: nn.n
■ K: nn.n
Pixel count values of colors Y/M/C/K.
(Read only.)
Configuration
■ Dip Switch 0
■ Dip Switch 1
■ Dip Switch 2
■ Dip Switch 3
Displays the dip switch setting. (Read
only.)
Meter Type
■ Type 1
■ Type 2
■ Type 3
■ Type 4
Displays the meter type. (Read only.)
Print Counter
■ Full Color Print
■ Color 1 Print
■ Color 2 Print
■ B/W Print
■ Tota l Print
■ Full Color Backup
■ Color 1 Backup
■ Color 2 Backup
■ B/W Backup
■ Tota l Backu p
■ Full Color Error
■ Color 1 Error
■ Color 2 Error
■ B/W Error
Displays the respective counter values
in the master NVM and backup NVM.
(Read only)
Test LCD (Phaser 6010N) Test Description

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
