Xerox PHASER 6010 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-15
Troubleshooting
Motor Test
(continued)
Yell ow Toner Mo tor
Magenta Toner Motor
Cyan Toner Motor
Black Toner Motor
Toner Motors
Caution: When checking the toner
motors, stop the test within
3 seconds. Executing this
test for 3 seconds or longer
may cause damage to the
printer.
DBAC ON
NOTE The use of DBAC ON, DBDC ON, TR1+
ON, TR2+ ON, TR2- ON, CR ON, MOB
LED ON, ADC LED ON, 24V ON, HV CLK
ON is prohibited to avoid shock hazards
since they are high-voltage outputs.
DBDC ON
TR1+ ON
TR2+ ON
TR2- ON
CR ON
MOB LED ON
ADC LED ON
24V ON
HV CLK ON
NVM Settings Edits, saves, loads, and prints NVM information.
Edit NVM
■ Ad0000=00000000*
■ Please wait
Displays current NVM values. Use this
function to edit NVM information.
Caution: Change NVM values only
when directed to do so by a
troubleshooting procedure.
Save NVM to ESS Save NVM
■ Save NVM MCU -> ESS
OK?
■ Saved
■ Please wait
Saves the MCU Board NVM to the IP
Board temporarily when the MCU
needs to be replaced.
LoadNVM from ESS Load NVM
■ Save NVM ESS -> MCU
OK?
■ Saved
■ Please wait
Loads the internal data saved via
NVM Settings - SaveNVM to ESS to
the new MCU Board
Print Info Provides printer configuration and settings information.
Info Page
■ Ready
■ Processing
Prints version information. The
Configuration Page contains:
■ Engine ROM Revision No.
■ MCU NVM Revision No.
Test LCD (Phaser 6010N) Test D es cr ipti o n

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
