Xerox PHASER 6010 Service Manual

4-56 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Troubleshooting
Y/M/C/K Toner Motor
1. Remove the Left Side Cover and main paper tray harness guide.
2. Enter Service Diagnostics (page 4-11).
3. Run the Color Mode Solenoid test: Printer > IOT Diag > Digital Output > DO-
X, where X is one of the following:
•Yellow Toner Motor: DO-10
•Magenta Toner Motor: DO-12
• Cyan Toner Motor: DO-14
• Black Toner Motor: DO-16
4. Remove the toner cartridge under test.
5. Check that the toner motor gear rotates.
6. Press the Stop button to stop the test.
7. Replace the toner cartridge and close the Toner Door.

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
