Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-55
Troubleshooting
K Mode Solenoid
1. Remove the Left Side Cover and main paper tray harness guide.
2. Enter Service Diagnostics (page 4-11).
3. Run the K Mode Solenoid test: Printer > IOT Diag > Digital Output > DO-b.
4. Check K Mode Solenoid movement.
5. Press the Stop button to stop the solenoid test.
6. Replace the harness guide and Left Side Cover.
To Next Page
