Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-59
Troubleshooting
RX Power Rx Call Detection Level 0: -36 dB, 1: -37 dB, 2: -38 dB, 3: -39 dB,
4: -40 dB, 5: -41 dB, 6: -42 dB, 7: -43 dB,
8: -44 dB, 9: -45 dB, 10: -46 dB,
11: -47 dB, 12: -48 dB
TX Power Tx Cable Equalizer 0: 0 dB, 1: 2 dB, 2: 4 dB, 3: 6 dB, 4: 8 dB,
5: 10 dB, 6: 11 dB, 7: 12 dB
Tx Signal Level 0: -3 dB, 1: -4 dB, 2: -5 dB, 3: -6 dB,
4: -7 dB, 5: -8 dB, 6: -9 dB, 7: -10 dB,
8: -11 dB, 9: -12 dB, 10: -13 dB,
11: -14 dB, 12: -15 dB, 13: -16 dB,
14: -17 dB, 15: -18 dB
External Hook
Threshold
High voltage High (20~40 V)
Medium voltage Medium (10~19 V)
Low voltage Low (5~9 V)
FAX Capability
Setting
Best Coding Capability 0: MH, 1: MR, 2: MMR, 3: JBIG
Backup Data
All Clear Clears all of the backup data.
User & System Clear Clears the stored document data, the
address information, the
communication management data, and
the history. Initializes the system data.
System Data Init Initializes the system data.
Complete Exits the diagnostics and returns to
normal operation, taking the changes of
the data into effect.
Tes t
Control Panel
(WorkCentre 6015N/NI
Color MFP)
Description
To Next Page
