A-8 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Reference
Digital Input
This function checks whether the Digital Input components operate normally or
not. The Digital Input test is performed for all the Digital Input components. Select
the component to test from the drop down list box, and then click the OK button.
LOW or HIGH is displayed on the Result screen. The component operation is
checked in such a way that the component status is changed from LOW to HIGH
and vice versa by operating the actuator or opening/closing the door. To stop the
operation, click the Stop button.
The following items are available for test.
PANEL Test
Phaser 6010N
Tests the buttons of the Control Panel.
This test checks input and output of the Control Panel. When
the Control Panel buttons are pressed, the test displays the
corresponding contents on the LCD.
Button LCD Display
Up Arrow Displays “UP”.
Down Arrow Displays “DOWN”.
Left Arrow Displays “LEFT”.
Right Arrow Displays “RIGHT”.
OK Displays “SET”.
Menu Displays “MENU”.
Cancel Displays “UP”.
Up Arrow
and Down
Arrow
pressed at
same time
Displays “Start”.
PANEL Test
Phaser 6000B
OK Illuminates amber LEDs.
Cancel Illuminates green LEDs.
OK/Cancel Press both OK and Cancel to end PANEL Test.
Engine Test Communication test with the IOT.
Execute this test when the 024-371 error occurs.
Test result:
NG: See “MCU Comm Error” on page 3-51.
OK: Turn off/on the main power.
Test Description
NO PAPER SNR Tests the No Paper Sensor.
REGI SNR Tests the Registration Sensor.
EXIT SNR Tests the Exit Sensor.
K MODE SNR Tests the K Mode Sensor (color mode
switching sensor).
IL OPEN Tests the Rear Door Interlock Switch.
FAN ALARM Not used.
CRU Y/ CRU M/ CRU C/ CRU K Tests the Toner Cartridge sensors.
To Next Page
