Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only A-9
Reference
Digital Input Test Procedures
All of the diagnostic test procedures in the following table can be accessed from
the CE Diag tab. Select Digital Input, and then select the test from the Digital
Input Number drop down list.
CRUM Sensors (K, C, M, Y)
Exit Sensor
Interlock Switch
(Cover Open Sensor)
Registration
Sensor
No Paper Sensor
K Mode Sensor
s6000-140
To Next Page
