Xerox PHASER 6010 Service Manual

A-16 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Reference
Digital Output Test Procedures
This group of diagnostics checks whether the DO components operate. As many as
ten different components can be simultaneously operated. However, it is
recommended to operate only one or two components at a time. Simultaneous
operation of many different components can break them.
Note
The use of DBAC ON, DBDC ON, 24V ON, HV CLK ON, TR1+ ON, TR2+ ON,
TR2- ON, CR ON, MOB LED ON, and ADC LED ON is prohibited to avoid shock
hazards since they are high-voltage outputs.
Item Item
MAIN MOTOR ON FULL REGI CLUTCH ON
MAIN MOTOR ON HALF DBAC ON
MAIN MOTOR OR SLOW DBDC ON
FEED SOLENOID ON 24V ON
K MODE SOLENOID ON HV CLK ON
FAN ON (HIGH) TR+ ON
FAN ON (LOW) TR2+ ON
TONER MOTOR Y ON TR2- ON
TONER MOTOR M ON CR ON
TONER MOTOR C ON MOB LED ON
TONER MOTOR K ON ADC LED ON

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
