Supported Postcard Sizes
Postcard Size Feed Direction
101.6 x 152.4 mm (4 x 6 in.) Short Edge Feed (SEF)
A6, 148 x 105 mm (5.8 x 4.1 in.) Short Edge Feed (SEF)
Loading Postcards in Trays 8 and 9
Note: Install the postcard bracket before printing postcards.
1. Slowly open one of the paper trays until it stops and remove the paper.
2. Move the paper guides out to their largest position.
3. To remove the postcard bracket, loosen the screw on the left side of the tray (1) and remove the
bracket (2).
4. Install the postcard bracket:
Xerox
®
Versant
®
4100 Press
User Documentation
177
