19 Reference
408 InfiniiVision 7000B Series Oscilloscopes User’s Guide
N2881A InfiniiMax DC blocking caps (qty 2), withstand up to 30 V DC, to be used with
InfiniiMax probe amplifiers and heads
N2882A 75 ohm-to-50 ohm adapter, DC to 8 GHz bandwidth, 5.7 dB attenuation
W2637A LPDDR BGA probe, x16, 404 MHz, 100 ohm input impedance
W2638A LPDDR BGA probe, x32, 404 MHz , 100 ohm input impedance
W2639A Oscilloscope Adapter Board, 1.5 GHz, 75 ohm input impedance
N5450A InfiniiMax Extreme Temperature Extension Cables, to be used with InfiniiMax
probe amplifiers and heads, 92 cm (36 in)
N2791A Differential probe, 1 MOhm termination, 10:1 or 100:1 (switchable), 25 MHz
N2792A Differential probe, 50 Ohm termination, 10:1, 200 MHz, compatible with all
InfiniiVision 7000B Series models
N2793A Differential probe, 50 Ohm termination, 10:1, 800 MHz, compatible with all
InfiniiVision 7000B Series models
1156A Active Probe, 1.5 GHz
1144A Active Probe, 800 MHz (requires 1142A – power supply)
1145A
†
Active Probe, 750 MHz 2-ch (requires 1142A – power supply)
1130A
†
For active differential probes: 1.5 GHz InfiniiMax amplifier (requires one or more
InfiniiMax probe head – E2675A, E2668A, E2669A).
N2772A Active Differential Probe, 20 MHz, 1.2 kVDC + peak AC max (requires N2773A
power supply)
1141A Active Differential Probe, 200 MHz, 200 VDC + peak AC max (requires 1142A
power supply)
1146A Current Probe, 100 kHz, 100 A, AC/DC
1147A
†
Current Probe, 50 MHz, 30 A, AC/DC with AutoProbe interface
N2780A Current Probe, 2 MHz, 500 A, AC/DC (use with N2779A power supply)
N2781A Current Probe, 10 MHz, 150 A, AC/DC (use with N2779A power supply)
N2782A Current Probe, 50 MHz, 30 A, AC/DC (use with N2779A power supply)
N2783A Current Probe, 100 MHz, 30 A, AC/DC (use with N2779A power supply)
Table 11 Accessories Available for 7000B Series Oscilloscopes (continued)
Model Description
