420 InfiniiVision 7000B Series Oscilloscopes User’s Guide
File Header
12 bytes
Waveform Header 2
140 bytes
Waveform Data
Header 1
12 bytes
Pod 1 Timing Data
buffer size
Waveform Data
Header 2
12 bytes
Pod 2 Timing Data
buffer size
Number of Waveforms = 2
Number of Waveform Buffers = 1
Buffer Type = 6 (unsigned char)
Bytes per Point = 1
Buffer Type = 6 (unsigned char)
Bytes per Point = 1
Waveform Header 1
140 bytes
Number of Waveform Buffers = 1
