Displaying Waveforms 3
InfiniiVision 7000B Series Oscilloscopes User’s Guide 75
3 Press the navigation keys to play backward, stop, or play
forward in time. You can press the or keys multiple times to
speed up the playback. There are three speed levels.
To navigate marks in the Lister
When acquisitions are stopped and serial decode is enabled, you can use
the navigation controls to go to marks in the Lister (set using the [Search]
key and menu).
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Search.
3 Press the back and forward keys to go to the previous or next
mark.
4 Press the stop key to set or clear a mark.
The Auto zoom softkey specifies whether the waveform display is
automatically zoomed to fit the marked row as you navigate.
Pressing the Scroll Lister softkey lets you use the Entry knob to scroll
through data rows in the Lister display.
To navigate segments
When the segmented memory acquisition is enabled and acquisitions are
stopped, you can use the navigation controls to play through the acquired
segments.
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Segments.
3 Press Play Mode; then, select:
• Manual — to play through segments manually.
In the Manual play mode:
• Press the back and forward keys to go to the previous or
next segment.
• Press the softkey to go to the first segment.
• Press the softkey to go to the last segment.
