27. Flywheel connector
28. Regulator connector
29. Regulator connector on the vehicle cable harness
TABLE I
Right side
30. Instrument panel branch vehicle cable harness
31. Fan connector 32. Clamp
TABLE J1 - EXHAUST VALVE ACTUATOR
Positioning and calibration
33. Exhaust valve actuator
34. Exhaust valve actuator cable harness routing
35. Exhaust valve actuator connector
36. Clamp
37. Spacer
38. Heat-protecting cover
39. Spacer
40. Rubber ring
Electrical system RSV4 R
ELE SYS - 110
