APRILIA RSV4 R User Manual

Removing
The steering damper steering more precise and
stable, improving motorcycle handling in all con-
ditions. The damper is fastened at the front of the
motorcycle between the base of the headstock
and the frame
Removal:
•
Undo the frame fixing screw operating
on the upper side through the hole.
•
Unscrew the fixing screw at the base of
the headstock.
•
Remove the steering damper.
Steering bearing
RSV4 R Suspensions
SUSP - 381

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
