Unscrew and remove the front screw.
See also
Side fairings
•
Unscrew and remove the lower screw.
•
Supporting the right fairing lug, un-
screw and remove the right lug fixing
screw and remove the lug.
•
Remove the left fairing lug in the same
manner.
Fuel tank
•
Unscrew and remove the front screw
fixing the tank.
RSV4 R Bodywork
BODYW - 461

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
