Remove the wheel spindle fixing nut.
•
Retrieve the sealing washer.
•
Loosen the screws on the wheel spin-
dle clamps.
•
Tap the wheel spindle slightly with a
rubber mallet so that the hole on the
opposite side is exposed.
•
Remove the wheel spindle by inserting
a screwdriver in the holes on the pin.
•
During extraction, support the wheel
and then remove it.
Checking the front wheel
FRONT WHEEL BEARINGS
Carry out the check with the bearings fitted on the wheel.
Suspensions RSV4 R
SUSP - 362

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
