APRILIA RSV4 R User Manual

•
Separate and remove the two semi-
arch braces
FITTING
•
Fit the right semi-arch brace, fixing it to
the headstock with two screws.
•
Connect the Immobilizer aerial cables.
•
Fasten the main cable harness to the
semi-arch brace with a clamp.
Bodywork RSV4 R
BODYW - 464
