APRILIA RSV4 R User Manual

Modify Keys
With this function the instrument panel can update the keys. Up to 4 keys can be stored.
The user code is first requested to be entered:
•
ENTER THE CODE
After entering the correct code, the following message should be shown on the display:
•
INSERT THE X KEY
•
INSERT THE X+1 KEY
At least one key must be programmed for the next start-ups. If no other key is inserted within 20 seconds
or if there is no power or after the fourth key is programmed, the procedure finishes and all the functions
of the vehicle and the instrument panel must be enabled (even if only one key has been programmed).
Km / miles
This menu selects the unit of measurement, either for the speed or the total or partial odometers.
•
KM
•
MILES
LANGUAGES
Select the user interface language from this menu.
•
ITALIANO
•
ENGLISH
•
FRANCAIS
•
DEUTSCH
•
ESPAÑOL
Service warning light reset
VEHICLE SERVICING RESET
This function is used to reset vehicle servicing. Using this function, the odometer can be reset only once
within the first 200 km (124 mi) of the vehicle, provided this has not been done by the Quality Check.
In order to activate this function follow the instructions in the DIAGNOSIS section.
See also
Diagnosis
Electrical system RSV4 R
ELE SYS - 140

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
