APRILIA RSV4 R User Manual

WATER PUMP
pos.
Description Type Quantity Torque Notes
1 Screws fastening the pump to the
crankcase
M6x25 2 10 Nm (7.37 lbf ft) -
Recommended products chart
RECOMMENDED PRODUCTS
Product
Description Specifications
AGIP TEC 4T, SAE 15W-50 Engine oil Use branded oils with performances
equal to or exceeding CCMC G-4 A.P.I.
SG. SAE 15W-50 specifications
AGIP MP GREASE Grease for bearings, joints, couplings
and linkages
As an alternative to the recommended
product, use top branded grease for roller
bearings with an operating temperature
range of -30°C to +140°C (-22°F to +284°
F), a drop point between 150°C and 230°
C (302°F and 446°F), high corrosion pro-
tection qualities and good water and rust
resistance.
AGIP PERMANENT SPEZIAL Coolant Ready for use mixed biodegradable cool-
ant with "long life" technology and char-
acteristics (red). Freezing protection up to
-40°C. Compliant with CUNA 956-16
standard.
AGIP BRAKE 4 Brake fluid As an alternative to the recommended
fluid, other fluids that meet or exceed the
required specifications may be used.
SAE J1703, NHTSA 116 DOT 4, ISO
4925 Synthetic fluid
AGIP FORK 7.5W Fork oil - (R) SAE 7.5W
Characteristics RSV4 R
CHAR - 50

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
