APRILIA RSV4 R User Manual

Driving mirrors
•
The following procedure is for a single
rear view mirror, but is applicable to
both mirrors.
•
Unscrew and remove the two nuts,
supporting the rear view mirror.
•
Disconnect the turn indicator connec-
tor from the relative fixed connector on
the instrument panel.
•
Guiding the turn indicator cable through the relative hole on the windshield, remove the rear
view mirror.
RSV4 R Bodywork
BODYW - 451

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
