APRILIA RSV4 R User Manual

•
At each removal, replace the inner gas-
ket between the pump casing and the
cover and the O ring on the pump cas-
ing.
ENSURE THAT THE LIQUID PASSAGE ORIFICES ARE
NOT OBSTRUCTED.
Removing the radiator
•
Drain off the cooling system.
•
Remove the front underfairings and the
hand grip position sensor
•
Disconnect both cooling fan connec-
tors.
•
Disconnect the expansion tank breath-
er pipe from the pipe grommet.
See also
Coolant replacement
Fairing mounting panels
RSV4 R Cooling system
COOL SYS - 439

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
