APRILIA RSV4 R User Manual

Checking the clutch housing
Check the clutch bell for damage and wear that may result in clutch irregular operation. If necessary,
replace the bell.
Check the riveted joint between the clutch bell and the primary drive sprocket for correct sealing and
evenness.
Check the primary drive gear for damage and wear
and, if necessary, replace the primary drive gear
and the clutch bell all together.
Make sure there is not excessive noise during op-
eration; if necessary, replace the primary drive
gear and the clutch bell all together.
Checking the pusher plate
Check the thrust plate and the bearing for damage and wear. If necessary, replace the parts.
Characteristic
Maximum deformation permitted on the spring
holder plate compression surface
0.15 mm (0.0059 in)
Maximum depth of the spring holder plate
27.3 mm (1.07 in)
Checking the clutch hub
Check the clutch hub for damage and wear that
may result in clutch irregular operation. If neces-
sary, replace the hub.
Engine RSV4 R
ENG - 266

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
