APRILIA RSV4 R - Completion of the Front

TABLE N - COMPLETION OF THE FRONT
65. Headlamp connectors
66. Headlamp connector positioning (as shown in the figure)
TABLE O - COMPLETION OF THE FRONT
Check that the turn indicator connectors are inserted correctly and do not return inside the
instrument holder arch brace.
67. Front right turn indicator connectors
68. Front left turn indicator connector
Electrical system RSV4 R
ELE SYS - 106
