Disconnect the lower injector connec-
tors.
See also
Air box
•
Disconnect the connector.
•
Remove the complete throttle body.
Checking the throttle body
The throttle bodies are maintenance free and are
not serviceable. Replace the entire assembly in
the event of malfunction.
As all the internal components of the throttle body
assembly (potentiometers and electrical motor)
are contactless, no electrical diagnosis is possible.
Functional tests are performed on the throttle body
assembly by the control unit during vehicle oper-
ation, with the results visible on the diagnostic
instrument.
The only action possible before replacing the com-
ponent is checking the connectors and cable har-
nesses.
RSV4 R Power supply
P SUPP - 355

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
