APRILIA RSV4 R User Manual

Removing the catalytic converter
•
Remove the exhaust end.
•
Remove the front exhaust manifold.
•
Remove the pinion crankcase
•
Disconnect the oxygen sensor connec-
tor.
•
Release the oxygen sensor cable har-
ness from the clamps.
•
Disconnect the two exhaust butterfly
valve control cables
•
Unscrew and remove the screw from
the cable grommet for the two exhaust
butterfly valve control cables.
•
Release the springs between the rear
exhaust manifolds and the catalytic
converter
•
Remove the catalytic converter.
Removing the exhaust manifold
2 IN 1 FRONT EXHAUST MANIFOLD
Chassis RSV4 R
CHAS - 414

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
