APRILIA RSV4 R User Manual

Side stand input PIN 70
Gear input PIN 72
Injection relay control output PIN 73
Upper cylinder 3 injector control output PIN 74
Variable geometry control unit failure input PIN 76 (If available)
"engine stop" input PIN 78
Vehicle speed input PIN 79
CAN H line (high speed) PIN 80
Engine - vehicle connector pinout key:
Key PIN 1A
Vehicle speed PIN 2A
STOP lights relay control output PIN 3A
- PIN 4A
- PIN 5A
- PIN 6A
Analogue ground connection 2 PIN 7A
Direct power supply to control unit PIN 8A
Injection supply PIN 1B
CAN H PIN 2B
CAN L PIN 3B
Key PIN 4A
Electric fan relay control PIN 5B
Fall sensor PIN 6B
Variable geometry power supply PIN 7B
Power ground connection 2 PIN 8B
Injection power supply PIN 1C
Serial line K for diagnosis PIN 2C
Clutch sensor PIN 3C
"Start engine" switch PIN 4C
Start-up control PIN 5C
Injection relay PIN 6C
Engine stop PIN 7C
Power ground connection 2 PIN 8C
Electrical system RSV4 R
ELE SYS - 218

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
