CENTRAL Q1 - NOTES FOR ENGINE CABLE
HARNESS FITTING
Definition of component numbering:
Upper view
77. Cylinder 1
78. Cylinder 2
79. Cylinder 3
80. Cylinder 4
81. Cylinder bank 1
82. Cylinder bank 2
83. Throttle body 1 (FARF 1)
84. Throttle body 2 (FARF 2)
CENTRAL Q2
Right side view
86. Engine speed sensor
87. Starter motor
Left side view
87. Starter motor
88. Alternator
89. Gear sensor
TABLE R - ENGINE CABLE HARNESS LAYOUT
RSV4 R Electrical system
ELE SYS - 115
