A small difference between the estimated pressure and the measured pressure has been
detected: the measured pressure is higher than the estimated one (for example, the pipe
between sensor and throttle body is squashed or there is a hole in the intake manifold).
Troubleshooting
•
Check the pneumatic system between the pressure sensor and the socket to read pressure
on the throttle body; check that the intake manifold is in good conditions and the pressure
reading hole is clean.
Estimation error for rear cylinder intake manifold pressure P0215
•
too high pressure/too low pressure.
Error cause
•
A substantial difference between the estimated pressure and the measured pressure has
been detected (for example, the pipe between sensor and throttle body is fully detached/
clogged or squashed).
Troubleshooting
•
Check the pneumatic system between the pressure sensor and the socket to read pressure
on the throttle body; check that the intake manifold is in good conditions and the pressure
reading hole is clean: there is an evident defect in the intake and pressure reading systems.
Estimation error for front cylinder intake manifold pressure P0216
•
too high pressure/too low pressure.
Error cause
•
A substantial difference between the estimated pressure and the measured pressure has
been detected (for example, the pipe between sensor and throttle body is fully detached/
clogged or squashed).
Troubleshooting
•
Check the pneumatic system between the pressure sensor and the socket to read pressure
on the throttle body; check that the intake manifold is in good conditions and the pressure
reading hole is clean: there is an evident defect in the intake and pressure reading systems.
Pressure too low at rear cylinder manifold error P0217
•
signal not valid.
Error cause
•
A small difference between the estimated pressure and the measured pressure has been
detected: the measured pressure is below the estimated one (for example, smeared throttle
body).
Troubleshooting
RSV4 R Electrical system
ELE SYS - 165

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
