APRILIA RSV4 R User Manual

NOTE
WHEN REFITTING THE CONNECTORS, THE SLIDES MUST
MOVE FREELY TO THE END OF STROKE, WHICH HELPS
WITH THE INSERTION OF THE CONNECTOR: YOU MUST
HEAR THE RELEASE OF THE RETAINING TANG AT THE
END OF STROKE.
Radiator cover
•
Remove the side fairings.
•
Remove the fairing lug.
•
Working from both sides, unscrew and
remove the screw.
•
Supporting the radiator cover and
working from the right side of the vehi-
cle, unscrew and remove the screw
and retrieve the washer and the nut.
See also
Lower cowl
Side fairings
Bodywork RSV4 R
BODYW - 466
