The Blow-by system uses the rotation of the countershaft (1) to separate the engine oil into oil vapour
and liquid.
The oil vapours exit from the fitting (2) on the alternator cover and enter the air filter box whereas the
liquid returns to the oil sump.
SAS valve
SECONDARY AIR SYSTEM
pos.
Description Type Quantity Torque Notes
1 Secondary air system solenoid
screws
- 2 10 Nm (7.37 lbf ft) -
Diagram
Valve controlled by control unit which delivers as-
pirated air from the filter box to the exhaust mani-
folds.
The advantages of this function are twofold:
•
the catalytic converter reaches the op-
erating temperature more quickly;
•
it permits the use of richer mixtures in
some critical conditions (e.g. at idle or
low engine speeds).
RSV4 R Engine
ENG - 347

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
