APRILIA RSV4 R - Removing the Idle Gear

Removing the idle gear
•
Remove the clutch cover.
•
Remove the intermediate gear.
Start-up system check
IF THE DUAL STARTER GEAR TOOTHING IS DEFORMED AFTER STARTING, THE STARTER
ENGINE TOOTHING MUST BE CHECKED AS WELL.
Check the dual starter gear toothing (1) and the
freewheel gear (2) to see if the material is dam-
aged or deformed.
Engine RSV4 R
ENG - 256
