Move the radiator forward.
•
Unscrew and remove the three fan re-
tainers and retrieve the washers.
Coolant replacement
•
Remove both fairings.
•
Place a container with a suitable ca-
pacity under the coolant pump.
•
Remove the radiator cap/valve to help
the fluid drain out.
•
Unscrew and remove the system drain
screw and retrieve the seal washer.
•
Wait for the entire circuit to drain (en-
gine+pipes+radiator)
•
Refit the system drain screw complete
with a new washer.
FILLING
•
Via the filler orifice on the radiator, fill with the quantity of coolant (approx. 2.2 l - 0.48 UK
gal) necessary to reach the edge.
•
Fit the cap / valve.
Cooling system RSV4 R
COOL SYS - 436

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
