Supporting the windshield, move it for-
ward to the create the minimum space
necessary to work on the front bulb
connectors.
•
Disconnect the front bulb connectors.
•
Remove the windshield in a forward
motion.
Side fairings
SIDE FAIRINGS
The following procedure is relative to a single fair-
ing, but is applicable to both.
•
Remove the lower side fairing.
•
Unscrew and remove the three screws.
Bodywork RSV4 R
BODYW - 454
