is not engaged, at approx. 6000 rpm, throttles open very little because the requested torque is too low
(around 5-7°)
Rear throttle Potentiometer 1 (degrees)
•
Example value with key ON: 8°
•
Example value with engine on: 1.5°
With key set to ON, the throttle is kept in position by the springs (around 5 -7°). After the engine starts
up at idle, the throttle is kept close to the mechanical minimum (above or equal to 0.5°). When the gear
is not engaged, at approx. 6000 rpm, throttles open very little because the requested torque is too low
(around 5-7°)
Front throttle Potentiometer 1 (voltage)
•
Example value with key ON: 873 mV
•
Example value with engine on: 561 mV
Rear throttle Potentiometer 1 (voltage)
•
Example value with key ON: 883 mV
•
Example value with engine on: 536 mV
Front throttle Potentiometer 2 (voltage)
•
Example value with key ON: 4123 mV
•
Example value with engine on: 4426 mV
Rear throttle Potentiometer 2 (voltage)
•
Example value with key ON: 4113 mV
•
Example value with engine on: 4455 mV
Front throttle Potentiometer 2 (degrees)
•
Example value with key ON: 8.0°
•
Example value with engine on: 1.5°
With key set to ON, the throttle is kept in position by the springs (around 5 -7°). After the engine starts
up at idle, the throttle is kept close to the mechanical minimum (above or equal to 0.5°). When the gear
is not engaged, at approx. 6000 rpm, throttles open very little because the requested torque is too low
(around 5-7°)
Rear throttle Potentiometer 2 (degrees)
•
Example value with key ON: 8.2°
•
Example value with engine on: 1.6°
With key set to ON, the throttle is kept in position by the springs (around 5 -7°). After the engine starts
up at idle, the throttle is kept close to the mechanical minimum (above or equal to 0.5°). When the gear
is not engaged, at approx. 6000 rpm, throttles open very little because the requested torque is too low
(around 5-7°)
RSV4 R Electrical system
ELE SYS - 189

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
