Component position
in the electrical circuit
diagram
Component name Location on the vehicle
25 Recovery logic relay (urgent service) In the niche of the headstock, on the right
Electrical system installation
INTRODUCTION
Scope and applicability
The purpose of this document is to define the position of the engine cable harness, its rounting and how
it is fixed on the engine and the filter box, any potential problems and particular checks to be carried
out on the connections and routings in order to reach the objectives of vehicle reliability.
Materials used and corresponding quantities
The electrical system consists of the following cable harnesses and parts:
•
1 Vehicle cable harness
•
1 Front light cable harness
•
1 License plate frame cable harness
•
1 Positive battery cable
•
1 Battery - engine ground cable
•
1 Key switch
•
1 Speed sensor
•
1 Start-up relay
•
5 Relays
•
1 Protection relay
•
1 Horn
•
1 Fall sensor
•
1 Headlamp
•
1 Taillight
•
1 Instrument panel
•
1 Right rear view mirror with turn indicator
•
1 Left rear view mirror with turn indicator
•
1 Rear right turn indicator
•
1 Rear left turn indicator
•
1 Fuel pump unit
•
1 Stand switch
•
1 Exhaust valve actuator
•
1 Oxygen sensor
•
2 Fans
•
1 Right handlebar control
•
1 Left handlebar control
Electrical system RSV4 R
ELE SYS - 96
