APRILIA RSV4 R User Manual

Air box
FILTER BOX COVER REMOVAL
•
Remove the control unit.
•
Disconnect the air temperature sensor
connector.
•
Move the two rear coil connectors
See also
Control unit
•
Unscrew and remove the four upper
injector screws.
•
Move the upper injector mounting.
•
Disconnect the variable geometry in-
take system connector. (if connected)
Bodywork RSV4 R
BODYW - 458

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
