APRILIA RSV4 R User Manual

Km x 1000 1 10 20 30 40
Brake systems (6) I I I I I
Light circuit I I I I I
Stand switch I I I I
Safety switches I I I I I
Stop switches I I I I
Brake fluid (4) I I I I I
Coolant (4) I I I I I
Fork oil (7) R R
Engine oil (6) R R R R R
Light aiming I I I I
Fork oil seals (6) I R I R
Flexible coupling I I
Tyres - pressure/wear (2) I I I I I
Wheels (6) I I I I I
Tightening torques (6) I I I I I
Clutch cover, flywheel and oil sump screws tight-
ening
I I I I I
Fault warning light on instrument panel (1)
Fuel lines (5) I I I I
Clutch wear (7) I I
Brake pad wear (2) I I I I I
Spark plug
FRONT SPARK PLUGS
•
Remove the base of the air filter box.
•
Undo and remove the screw.
•
Slide off the front coil.
•
Unscrew and remove the front spark plug.
REAR SPARK PLUGS
Maintenance RSV4 R
MAIN - 62

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
