Using a dial gauge, check that the ra-
dial (A) and the axial (B) eccentricities
of the rim do not exceed the limit value.
An excessive eccentricity is usually
caused by worn or damaged bearings.
Replace the rim if, after replacing the
bearings, the value is not within the
specified limit.
Characteristic
Maximum radial and axial eccentricity:
0.8 mm (0.031 in)
Handlebar
HANDLEBAR AND CONTROLS
pos.
Description Type Quantity Torque Notes
1 Screw fastening the semi-handlebar
collar to the fork sleeves
M8 1 + 1 25 Nm (18.44 lbf ft) -
2 Semi-handlebar safety screw M6 1+1 10 Nm (7.37 lbf ft) -
3 Anti-vibration counterweight fastener M18x1.5 1+1 20 Nm (14.75 lbf ft) -
4 Right light switch M4 2 1.5 Nm (1.11 lbf ft) -
5 Left light switch M5 2 1.5 Nm (1.11 lbf ft) -
6 Throttle control fixing screws M5 2 2 Nm (1.47 lbf ft) -
Suspensions RSV4 R
SUSP - 364

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
