Side air deflectors
The following procedure is for a single lateral duct
but is applicable to both.
•
Remove the windshield.
•
Unscrew and remove the two fixing
nuts.
•
Remove the duct from its seat on the frame.
CAUTION
DURING REASSEMBLY, THE DUCT MUST BE SEATED CORRECTLY ON THE FRAME TO EN-
SURE THAT IT IS FLUSH WITH THE ADJACENT PARTS.
See also
Headlight fairing
RSV4 R Bodywork
BODYW - 467
