LATERAL UNDERFAIRINGS
•
The following procedure is relative to a
single lateral underfairing, but is appli-
cable to both, except where specified
otherwise.
•
Unscrew and remove the central un-
derfairing fixing screw.
•
Remove the respective side fairing.
•
Unscrew and remove the lower screw.
•
When working on the left hand side of
the vehicle, remove the underfairing
taking particular care not to damage
the fittings with the central underfair-
ing.
•
When working on the left hand side of
the vehicle, support the left hand un-
derfairing, unscrew and remove the
two nuts, retrieve the screws and lower
the regulator.
•
Remove the underfairing.
RSV4 R Bodywork
BODYW - 457

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
