APRILIA RSV4 R User Manual

TENANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE
VEHICLE.
Vehicle identification
SERIAL NUMBER LOCATION
These numbers are necessary for vehicle registration.
NOTE
ALTERING IDENTIFICATION NUMBERS MAY BE SERIOUSLY PUNISHABLE BY LAW. IN PAR-
TICULAR, MODIFYING THE CHASSIS NUMBER IMMEDIATELY VOIDS THE WARRANTY.
This number consists of numbers and letters, as in
the example shown below.
ZD4RKA000YSXXXXXX
KEY:
ZD4: WMI (World manufacturer identifier) code;
RK: model;
A00: version variation;
0: free digit
Y year of manufacture
S: production plant (S= Scorzè);
XXXXXX: serial number (6 digits);
CHASSIS NUMBER
The chassis number is stamped on the right side
of the headstock.
ENGINE NUMBER
The engine number is printed on the base of the
engine crankcase, left hand side.
Engine No. ....................
Dimensions and mass
WEIGHT AND DIMENSIONS
Specification
Desc./Quantity
Max. length 2040 mm (80.31 in)
Max width (at handlebar) 735 mm (28.94 in)
Max. height (to windshield) 1120 mm (44.09 in)
Saddle height 847 mm (33.35 in)
Wheelbase 1420 mm (55.90 in)
Minimum ground clearance 130 mm (5.12 in)
RSV4 R Characteristics
CHAR - 11

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
