APRILIA RSV4 R User Manual

•
Remove the clamps on the saddle
mounting.
CAUTION
PERFORM THE OPERATIONS BELOW AIDED BY A SECOND OPERATOR.
•
Lower the engine
•
Lift the front part of the vehicle.
•
Remove the front stand.
•
Release the belts from the hoist, supporting the front part of the vehicle.
•
Remove the rear stand.
•
Remove the chassis from the engine.
Installing the engine to the vehicle
•
Before aligning the engine retainers, fit right and left inserts on the engine, taking the pre-
cautions described above, checking that the holes are facing downwards.
CAUTION
THE REAR RIGHT AND REAR LEFT LOWER INSERTS ARE THE SAME.
Engine from vehicle RSV4 R
ENG VE - 234

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
