Inspecting the cover components
•
Unscrew and remove the three Blow-
by system fitting screws.
•
Remove the Blow-by system fitting.
•
Replace the O-ring with a new one of
the same type
•
Remove the flywheel cover.
•
Remove the circlip, thrust washer and
inner sealing ring or replace if they are
spoiled or in case of oil leaks.
See also
Removing the flywheel cover
Installing the flywheel
•
Position the flywheel on the crankshaft.
•
Block flywheel rotation using the spe-
cific tool.
•
Tighten the screw.
Specific tooling
020848Y Flywheel retainer
RSV4 R Engine
ENG - 259
