Central part
TABLE A - RADIATOR AREA
Right side
1. Cable grommet
2. Vehicle cable harness
TABLE B - RADIATOR AREA
Right side
3. Starter motor
4. Clamp
5. Exhaust valve actuator cable harness routing
6. Oil pressure sensor and cable harness routing
RSV4 R Electrical system
ELE SYS - 107

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
