APRILIA RSV4 R - Blow-By; Removing the Oil Sump

Removing the oil sump
•
Drain the engine oil.
•
Unscrew and remove the twelve oil
sump screws.
•
Remove the oil sump.
•
Remove the metal gasket.
•
Remove the rose pipe together with the
gasket.
DURING REFITTING REPLACE THE GASKET WITH A NEW
ONE OF THE SAME TYPE.
Blow-by
Engine RSV4 R
ENG - 346
