FRONT BRAKE CALLIPER
pos.
Description Type Quantity Torque Notes
1 Front brake calliper fixing screws M10x1.25 2 + 2 50 Nm (36.88 lbf ft) -
FRONT BRAKE PUMP
pos.
Description Type Quantity Torque Notes
1 Screw fastening front brake fluid res-
ervoir to bracket
M6 1 7 Nm (5.16 lbf ft) -
Characteristics RSV4 R
CHAR - 18
