Engine oil filter
Replace the engine oil filter each time you
change the engine oil.
•
Drain the engine oil completely.
•
Unscrew and remove the engine oil fil-
ter from its seat.
NOTE
NEVER REUSE AN OLD FILTER.
•
Spread a thin layer of oil on the sealing ring of the new engine oil filter.
•
Insert and screw the new engine oil filter in the seat, filling the filter to 1/3 of its capacity with
engine oil before fitting.
See also
Replacement
Air filter
•
Remove the fuel tank.
•
Unscrew and remove the eight air filter
box cover screws
•
Disconnect the upper injector fuel de-
livery union.
See also
Fuel tank
RSV4 R Maintenance
MAIN - 65

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APRILIA RSV4 R and is the answer not in the manual?

APRILIA RSV4 R Specifications

General IconGeneral
Displacement999.6 cc
Torque115 Nm @ 10, 000 rpm
Transmission6-speed
FrameAluminum dual beam chassis
Seat Height845 mm
Dry Weight179 kg
Bore x Stroke78 x 52.3 mm
Front Tire120/70 ZR17
Rear Tire190/55 ZR17
Wheelbase1420 mm
Power180 hp @ 12, 500 rpm
Front SuspensionUpside-down fork, 43 mm
Front BrakesDual 320 mm discs, radial calipers
Rear Brakes220 mm disc, Brembo caliper
Fuel SystemFuel injection
Fuel Capacity18.5 L (4.9 US gal)
