Indefinite_Start-up_Stable_Idle_Acceleration_Deceleration_Enters Cut Off_Cut Off_Exits
Cut Off
Immobilizer signal
•
yes/no
•
Indicates whether the control unit has received the consent by the instrument panel regard-
ing the immobilizer: coded key or user code entered manually. Potential errors will be shown
on the Instrument Panel Errors screen page, on the DIAGNOSIS section of the instrument
panel
Start-up enabling
•
yes/no
•
Indicates whether the control unit will enable start-up when requested: in case the safety
measures are not respected (side stand, neutral sensor and clutch in correct position) or the
fall sensor is inverted or if the immobilizer does not send the start-up consent to the control
unit, the status is NO
DIAGNOSIS INSTRUMENT: ACTIVATION
Stop light
•
The stop light logic relay (No 25 in the wiring diagram, position in the front niche of the frame,
right side, CHECK, however, the identification of the relay with the colour of the cables) is
energised
Error clearing
Ambient parameter reading
•
Rear throttle target position angle
•
Front throttle target position angle
•
Rear throttle position
•
Front throttle position
•
Engine Temp. before Recovery
•
Rear cylinder mean intake pressure (1 and 3)
•
Front cylinder mean intake pressure (2 and 4)
•
Engine rpm
•
Indicated average torque
•
Engine status - Indefinite_Key ON_Running engine_Stopped_Power latch_Power latch
2_Power latch finished
•
Odometer
•
Mapping selection - Indefinite/Track/Sport/Road
DIAGNOSIS INSTRUMENT: ELECTRICAL ERRORS
EEPROM Error P0601
RSV4 R Electrical system
ELE SYS - 145
