Remove the fuel tank.
•
Unscrew and remove the rear coil fixing screw.
•
Slide off the rear coil.
•
Unscrew and slide off the rear spark
plug.
Engine oil
Check
NOTE
HOT OIL IS LESS VISCOUS AND WILL DRAIN OUT MORE EASILY AND COMPLETELY.
•
Shut off the engine and wait for a few
seconds.
•
Keep the vehicle upright with both
wheels on the ground.
•
Ensure that the vehicle is on a level
surface.
•
Check, via the sight glass positioned
on the clutch casing, that the oil level
reaches at least three quarters of the
way up the sight glass itself.
•
If this is not the case, top-up the oil im-
mediately through the filler plug.
CAUTION
NEVER ALLOW THE OIL LEVEL TO DROP BELOW THE
MINIMUM LEVEL OR FILL ABOVE THE MAXIMUM LEVEL;
IF YOU DO NOT COMPLY WITH THE MINIMUM AND MAX-
IMUM OIL LEVELS THE ENGINE COULD BE SERIOUSLY
DAMAGED
Replacement
NOTE
HOT OIL IS LESS VISCOUS AND WILL DRAIN OUT MORE EASILY AND COMPLETELY.
RSV4 R Maintenance
MAIN - 63
