Checking the gear selector
Check the stop lever for damage and wear and
make sure the ball rotates freely.
If necessary, replace the parts.
Check the gear selector spring for damage and
wear.
If necessary, replace the part.
Check the selector shaft and its teeth for damage
and wear.
If necessary, replace the part.
Check the lever spring for damage and wear.
If necessary, replace the part.
Reassembling the gear selector
•
To refit, lubricate and carry out the removal operations but in reverse order.
Starter motor
Removing the starter motor
•
Unscrew the starter motor fixing
screws and pull it out of its housing.
RSV4 R Engine
ENG - 255
